A fixed dock leveler is a hydraulic loading platform installed at a permanent loading bay. It helps bridge the working height between the warehouse floor and a truck bed so forklifts and other material-handling equipment can move goods across the loading point.
The DCQG range includes verified 8-ton and 10-ton models for warehouses, factories, logistics centers, and distribution facilities. Three equipment lengths are listed, and every standard model uses a 1.1 kW power unit with three-phase 380 V power at 50 Hz or 60 Hz.
View Fixed Dock Leveler Models
Browse the available products below. The detailed comparison after the product list covers verified dimensions, platform and lip plate thicknesses, cylinder arrangements, power requirements, optional configurations, and the information needed for a quotation.
The DCQG range is available with an 8-ton or 10-ton rated load. All listed models are 2,000 mm wide and 600 mm high, with equipment lengths of 2,000 mm, 2,500 mm, or 3,000 mm.
During operation, the hydraulic platform adjusts upward or downward from the loading-bay level, and the lip forms the connection to the vehicle bed. Model selection should be based on the required rated load, available installation space, vehicle-bed height range, site power supply, and selected options.
The DCQG-8T uses eight U-shaped main beams, a 6 mm checker-plate platform, and a 14 mm checker-plate lip.
| Model | Equipment Size (L × W × H) | Upward / Downward Travel | Platform Cylinder | Platform / Lip Plate | Power Supply | Self-Weight |
|---|---|---|---|---|---|---|
| DCQG-8T | 2,000 × 2,000 × 600 mm | 400 / 300 mm | Single cylinder | 6 mm / 14 mm checker plate | 1.1 kW, 3-phase 380 V, 50/60 Hz | 600 / 624 kg |
| DCQG-8T | 2,500 × 2,000 × 600 mm | 400 / 300 mm | Single cylinder | 6 mm / 14 mm checker plate | 1.1 kW, 3-phase 380 V, 50/60 Hz | 700 / 718 kg |
| DCQG-8T | 3,000 × 2,000 × 600 mm | 400 / 300 mm | Dual cylinder | 6 mm / 14 mm checker plate | 1.1 kW, 3-phase 380 V, 50/60 Hz | 808 kg |
For rows with paired self-weight values, the figures are listed for the steel-plate and rectangular-tube versions respectively.
The DCQG-10T uses eight U-shaped main beams, an 8 mm checker-plate platform, and a 16 mm checker-plate lip.
| Model | Equipment Size (L × W × H) | Upward / Downward Travel | Platform Cylinder | Platform / Lip Plate | Power Supply | Self-Weight |
|---|---|---|---|---|---|---|
| DCQG-10T | 2,000 × 2,000 × 600 mm | 400 / 300 mm | Single cylinder | 8 mm / 16 mm checker plate | 1.1 kW, 3-phase 380 V, 50/60 Hz | 680 / 700 kg |
| DCQG-10T | 2,500 × 2,000 × 600 mm | 400 / 300 mm | Single cylinder | 8 mm / 16 mm checker plate | 1.1 kW, 3-phase 380 V, 50/60 Hz | 770 / 808 kg |
| DCQG-10T | 3,000 × 2,000 × 600 mm | 400 / 300 mm | Dual cylinder | 8 mm / 16 mm checker plate | 1.1 kW, 3-phase 380 V, 50/60 Hz | 926 kg |
For rows with paired self-weight values, the figures are listed for the steel-plate and rectangular-tube versions respectively.
Every listed model has 400 mm upward travel and 300 mm downward travel. The 2,000 mm and 2,500 mm models use a single platform cylinder; the 3,000 mm models use dual platform cylinders.
The standard fixed dock leveler uses a 1.1 kW power unit with three-phase 380 V power and supports both 50 Hz and 60 Hz. A standard hydraulic power unit is covered by a five-year warranty.
A fixed dock leveler is normally planned together with its loading-bay installation area. Confirm the civil dimensions with the supplier before preparing the installation pit or placing an order.
Before requesting a quote, provide:
Custom dimensions require confirmation with the supplier. Monthly production capacity is listed as 500 sets, with customization and expedited delivery available.
Fixed hydraulic dock levelers are intended for facilities with permanent loading and unloading positions. Typical project environments include:
A fixed dock leveler is a hydraulic platform installed at a permanent loading bay. It adjusts between the loading-bay level and a vehicle bed to provide a loading connection.
The listed range includes the 8-ton DCQG-8T and the 10-ton DCQG-10T.
The listed equipment sizes are 2,000 × 2,000 × 600 mm, 2,500 × 2,000 × 600 mm, and 3,000 × 2,000 × 600 mm.
Every listed DCQG-8T and DCQG-10T model has 400 mm upward travel and 300 mm downward travel.
The standard configuration is 1.1 kW, three-phase 380 V, and 50/60 Hz. Single-phase 220 V is listed as an option.
Yes. Custom dimensions require supplier confirmation. Listed options include control, cylinder, valve, power-supply, color, dust-brush, vehicle-restraint, and operating-mode configurations.
Provide the required rated load, loading-bay height, vehicle-bed height range, available installation space, planned pit dimensions, site power supply, selected options, and loading-area photos or drawings when available.
Send us your required load capacity, equipment size, site voltage, frequency, and selected options. We will confirm the suitable DCQG configuration and provide a quotation for your warehouse or logistics project.
