10 Ton Fixed Dock Leveler for Warehouse Loading Bays

The DCQG-10T fixed hydraulic dock leveler is designed for permanent warehouse and logistics loading positions requiring a 10-ton rated load. This pit-mounted dock leveler is available in three equipment lengths. All listed versions are 2,000 mm wide and 600 mm high.

The platform provides 400 mm upward travel and 300 mm downward travel. An 8 mm checker-plate platform and 16 mm checker-plate lip are used across the DCQG-10T range.

DCQG-10T Key Specifications

• Rated load: 10 tons
• Available lengths: 2,000 mm, 2,500 mm, and 3,000 mm
• Equipment width: 2,000 mm
• Equipment height: 600 mm
• Upward / downward travel: 400 / 300 mm
• Platform plate: 8 mm checker plate
• Lip plate: 16 mm checker plate
• Power unit: 1.1 kW
• Standard power supply: Three-phase 380 V, 50/60 Hz

Available DCQG-10T Sizes

For rows with paired self-weight values, the figures are listed for the steel-plate and rectangular-tube versions respectively.

Platform Construction and Power Supply

Platform Configuration

• Eight U-shaped main beams
• 8 mm checker-plate platform
• 16 mm checker-plate lip
• Single platform cylinder on the 2,000 mm and 2,500 mm versions
• Dual platform cylinders on the 3,000 mm version

Standard Power Configuration

• 1.1 kW power unit
• Three-phase 380 V
• 50 Hz or 60 Hz
• Five-year warranty for the standard hydraulic power unit

Available DCQG-10T Options

• Single-phase 220 V power
• 1.1 kW CT4 explosion-proof configuration
• Dual platform cylinders
• Intelligent electrical control box
• Dust brushes
• Wireless remote control
• Custom color
• Explosion-proof valve for a single- or dual-cylinder configuration
• Vehicle restraint
• Brevini self-pressure-relief configuration, with or without valve
• Bucher self-pressure-relief configuration, with or without valve
• Solenoid valve
• Combined manual and electric operation

How to Select a 10 Ton Warehouse Dock Leveler

Before ordering a fixed dock leveller, confirm the available installation space, loading-bay height, vehicle-bed height range, planned pit dimensions, and site power supply. Choose the equipment length according to the project dimensions and confirm all civil measurements with the supplier before preparing the pit.

For model confirmation and a quotation, provide:

• Required equipment size
• Loading-bay and vehicle-bed heights
• Available installation space and planned pit dimensions
• Site voltage and frequency
• Required options
• Loading-area photos or drawings, when available

Typical Applications

The DCQG-10T hydraulic loading dock leveler is intended for permanent loading positions in warehouses, factories, logistics centers, distribution facilities, and other truck-loading areas requiring a 10-ton rated load.
